X-ray Inspection

PCB X-Ray Inspectio n Services for High-Reliability Electronics

Sierra Assembly provides advanced PCB X-Ray Inspection Services for aerospace, defense, medical, industrial, automotive, and high-reliability electronics manufacturers across the United States. With over 30 years of electronics manufacturing experience, our US-based, certified facility delivers precise X-ray inspection solutions designed to detect hidden PCB assembly defects before they impact performance, reliability, or compliance.

We operate under AS9100 Rev-D and ISO 9001:2015 certified quality systems and comply with RoHS standards, helping you meet the strict requirements of modern electronics manufacturing. Our experienced engineering team combines advanced X-ray inspection technology with proven quality control processes to help reduce manufacturing risks, improve assembly reliability, and support long-term product performance.



Whether you need prototype PCB inspection, BGA X-ray analysis, or production-level inspection support, Sierra Assembly delivers fast turnaround, detailed inspection insight, and trusted engineering support for mission-critical applications.

Get a Quote | Upload Your Files | Talk to Our Engineers

Advanced PCB X-Ray Inspection Capabilities in Chino, California

As PCB assemblies become smaller, denser, and more complex, hidden solder defects and internal connection failures are increasingly difficult to identify through standard visual inspection. Critical issues beneath BGA packages, multilayer boards, and fine-pitch components often remain invisible without advanced X-ray analysis.



Sierra Assembly provides high-resolution PCB X-Ray Inspection Services designed to verify solder joint integrity, detect hidden assembly defects, and support high-reliability electronics manufacturing. Our X-ray inspection process helps manufacturers improve assembly quality, reduce costly rework, and prevent hidden defects from impacting field performance.

Our PCB X-Ray Inspection Services support:

• BGA assemblies
• Fine-pitch components
• Multilayer PCBs
• SMT assemblies
• High-density electronic designs
• Prototype PCB builds
• Low-volume and high-volume production
• Mission-critical electronic applications

We help manufacturers identify defects early, improve production yield, and ensure dependable electronic performance before products move into deployment.

PCB X-Ray Inspection Capabilities

Our PCB X-Ray Inspection Services help manufacturers identify and analyze hidden defects that can affect product quality, reliability, and long-term performance.
We inspect for:

• Solder joint shorts and opens
• Solder voids and insufficient solder
• Cracked or cold solder joints
• BGA alignment issues
• Hidden BGA connection defects
• Component placement concerns
• Internal PCB connectivity issues
• Reflow and solder performance issues
• Bridging and hidden solder defects

These inspection capabilities help reduce costly rework, improve production quality, and support reliable performance in demanding electronic applications.

Choosing the Right PCB Inspection Method

Selecting the right inspection method is critical for identifying hidden PCB assembly defects and maintaining long-term product reliability. Different inspection methods provide different levels of visibility depending on the defect type, component package, and board complexity.

The comparison below shows why PCB X-Ray Inspection is essential for hidden solder joints, BGA assemblies, and internal PCB structures.

Defect Type	PCB X-Ray Inspection	Traditional Optical Inspection
Open circuits	Yes	Yes
Solder bridges	Yes	Yes
Solder shorts	Yes	Yes
Insufficient solder	Yes	Yes
Solder voids	Yes	Limited
Excess solder	Yes	Yes
Hidden solder joint quality	Yes	No
Lifted leads	Yes	Yes
Missing components	Yes	Yes
Misaligned components	Yes	Yes
BGA shorts	Yes	No
BGA open circuit connections	Yes	No
Internal PCB defects	Yes	No

Unlike surface-level inspection methods, PCB X-Ray Inspection allows manufacturers to inspect hidden solder joints, internal PCB layers, and BGA connections that cannot be visually verified. This makes X-ray inspection essential for high-density PCB assemblies, multilayer boards, and mission-critical electronics where reliability and defect prevention are critical.

Precision PCB X-Ray Inspection as Fast as 24 Hours. Need fast inspection support for a critical PCB assembly? Sierra Assembly provides responsive X-ray inspection services to help you identify hidden assembly defects before they delay production. Ensure solder joint reliability, reduce rework, and protect your production schedule. Upload Your PCB Files.

Key PCB X-Ray Inspection Highlights

• Advanced high-resolution PCB X-Ray Inspection
• Detailed analysis of hidden solder joints and internal PCB structures
• Detection of solder shorts, opens, voids, and bridging
• Precision inspection for BGA, LGA, QFN, and fine-pitch components
• High-clarity imaging for complex PCB assemblies
• Verification of solder integrity and component alignment
• Support for aerospace, defense, medical, automotive, and industrial electronics
• Fast turnaround and engineering-focused inspection support

How PCB X-Ray Inspection Works

PCB X-Ray Inspection uses high-resolution X-rays to examine hidden internal structures and solder joints inside electronic assemblies. Dense materials such as solder absorb more X-rays and appear darker in the inspection image, while lighter materials appear more transparent.
This process allows engineers to detect hidden defects such as:

• Open circuits
• Solder voids
• Shorts and bridges
• Misaligned components
• Cracked or insufficient solder joints
• BGA connection issues

PCB X-Ray Inspection is especially critical for BGA assemblies, multilayer PCBs, and high-density electronic components where defects cannot be identified through standard visual inspection.

Key Benefits of PCB X-Ray Inspection

Internal Defect Detection
PCB X-Ray Inspection identifies hidden defects such as solder voids, internal cracks, open connections, and multilayer PCB issues that are not visible from the surface.

Comprehensive PCB Analysis
X-ray imaging provides a detailed internal view of PCB assemblies, helping manufacturers verify solder joint integrity, component alignment, and overall assembly quality.

High-Precision Inspection
Advanced X-ray inspection delivers accurate defect detection for BGA assemblies, fine-pitch components, and high-density PCB applications where reliability is critical.

Reduced Rework and Production Risk
By detecting hidden defects early, manufacturers can reduce rework, minimize scrap, avoid production delays, and improve overall product quality.

Essential for High-Reliability Electronics
PCB X-Ray Inspection plays a critical role in aerospace, defense, medical, automotive, and industrial electronics where hidden assembly defects can impact long-term product performance and safety

Why Choose Sierra Assembly for PCB X-Ray Inspection?

Sierra Assembly is more than an inspection provider we are a trusted electronics manufacturing partner helping companies improve PCB reliability, reduce production risks, and maintain consistent assembly quality for critical applications.

With over 30 years of industry experience, our team provides precision PCB X-Ray Inspection Services backed by advanced inspection capabilities, engineering expertise, and responsive customer support.

Manufacturers choose Sierra Assembly for:

• Advanced PCB X-Ray Inspection expertise
• High-resolution defect detection for complex PCB assemblies
• Fast turnaround for prototype and production requirements
• Engineering-focused inspection support
• Precision analysis for BGA, SMT, and multilayer PCB assemblies
• Support for high-density and mission-critical electronic applications
• Reliable inspection processes for aerospace, medical, defense, automotive, and industrial electronics
• US-based manufacturing and responsive project communication
• Low-volume to high-volume production support
• Commitment to quality, reliability, and customer satisfaction

Our goal is to help you identify hidden PCB defects early, improve assembly performance, and ensure long-term product reliability with confidence.

If you are looking for reliable X-Ray Inspection Services, PCB X-Ray Inspection, or PCB X-Ray Inspection Service in California or anywhere in the United States, Sierra Assembly is ready to help. Get a Quote Today Our experienced team provides advanced inspection support for complex PCB assemblies, BGA components, multilayer boards, and high-reliability electronic applications.

Frequently Asked Questions (FAQs)

1. What types of PCB defects can X-Ray inspection detect?
Ans: PCB X-Ray Inspection can detect hidden defects such as solder voids, open circuits, shorts, bridging, insufficient solder, cracked solder joints, BGA connection failures, and internal PCB assembly issues that cannot be identified through standard visual inspection.

2. Why is PCB X-Ray Inspection important for BGA assemblies?
Ans: BGA components have hidden solder joints beneath the package, making visual inspection impossible. PCB X-Ray Inspection helps verify solder integrity, alignment, and connection reliability to prevent hidden assembly failures in high-density electronic applications.

3. How quickly can Sierra Assembly complete PCB X-Ray Inspection services?
Ans: Turnaround time depends on board complexity and project volume, but Sierra Assembly provides fast-response PCB X-Ray Inspection Services for both prototype and production requirements to help keep manufacturing schedules on track.

4. Do you support high-reliability industries such as aerospace and medical electronics?
Ans: Yes. Sierra Assembly supports aerospace, defense, medical, industrial, automotive, and other high-reliability electronics industries that require precision PCB inspection, quality assurance, and dependable assembly verification.

5. Can PCB X-Ray Inspection help reduce manufacturing failures and rework?
Ans: Yes. PCB X-Ray Inspection helps identify hidden assembly defects early in the manufacturing process, reducing costly rework, improving production yield, and preventing field failures before products move into deployment.
